Standards Compliance
Flanges to ANSI, JIS and DIN.
Quality-Checked Materials
Carbon and stainless steel grades.
Technical Product Assistance
Help matching type, standard and grade.
Project-Based Sourcing
Flanges with pipes, fittings and valves.
Specifications
Flanges Supplier Malaysia: Flange Specifications
As a flanges supplier Malaysia projects can rely on, Meta Piping supplies carbon steel and stainless steel flanges for oil and gas, marine, utilities and manufacturing projects across the country.
| Type | Slip-On, Blind, Threaded |
| Standards | ANSI, JIS, DIN |
| Material | SS400, A105N, F304 / 304L, F316 / 316L |
Send your size and quantity to sales@meta-piping.com and our team will confirm availability. Our flanges follow standards published by ASME, JISC and DIN.
Our Range
Flanges for Sale in Malaysia: Types We Supply
Slip-On Flanges
A slip-on flange slides over the outside of the pipe and is fillet welded on both sides. It is easy to align and install, and is commonly used on lower-pressure lines and general service piping.
Blind Flanges
A blind flange is a solid plate with no bore. It is bolted to close off the end of a pipe, valve or vessel opening, and allows the line to be extended or opened for inspection later.
Threaded Flanges
A threaded flange has an internal thread that screws onto a threaded pipe, so no welding is needed. It is useful where welding is impractical or unsafe, typically on smaller-bore, lower-pressure lines.
Want to compare all flange types, including weld neck, socket weld, lap joint and orifice flanges? Read our guide: 7 Types of Flanges Explained, then contact us to discuss your requirement.
Flange Materials: Carbon Steel and Stainless Steel
| Material | Description | Typical Use |
|---|---|---|
| SS400 | Carbon structural steel to JIS G3101 | General low-pressure and structural service |
| A105N | Forged carbon steel to ASTM A105, normalised | Process and oil and gas piping |
| F304 / 304L | Austenitic stainless steel | General corrosion-resistant service |
| F316 / 316L | Stainless steel with added molybdenum | Marine, chloride and chemical environments |
Flange Standards: ANSI, JIS and DIN
ANSI
ANSI / ASME flanges are rated by pressure class and are widely used in oil and gas and process plants.
JIS
JIS flanges follow Japanese Industrial Standards and are common on Japanese-built equipment and in marine work.
DIN
DIN flanges follow German standards with PN pressure ratings and appear on European equipment. Always match the standard of the mating flange so that bolt holes, dimensions and facings line up.
Industries We Supply
Flanges for Malaysia's Industrial Projects
See the companies we have supplied on our project references page.
Ordering
How to Buy Flanges in Johor Bahru, Malaysia
Meta Piping works on a quotation basis, so every order is checked against your specification before it is confirmed.
01
Send Your Requirement
Send the flange type, standard, size, material and quantity through our enquiry form or to sales@meta-piping.com.
02
Receive a Quotation
Our team confirms availability and sends a quotation.
03
Confirm Your Order
Confirm the order and we will arrange the next steps with you.
We are located at Taman Perindustrian Maju, Johor Bahru. If you would like to visit, please contact us in advance so the right team member is available.
Why Meta Piping
Why Buy Flanges from Meta Piping
- Based in Johor Bahru and supplying industrial clients across Malaysia
- Carbon steel and stainless steel flanges from one supplier
- Flanges to three international standards: ANSI, JIS and DIN
- Matching stainless steel pipes, butt weld fittings, forged fittings and valves for a complete piping system
- Trusted by industrial clients, see our project references
Complete Your System
Related Products
FAQ
Frequently Asked Questions About Flanges
Is Meta Piping a flanges supplier in Malaysia?
Yes. Meta Piping is a flanges supplier based in Johor Bahru, supplying slip-on, blind and threaded flanges to industrial clients across Malaysia.
What types of flanges do you supply?
We supply slip-on, blind and threaded flanges.
Which flange standards do you supply?
Our flanges are supplied to ANSI, JIS and DIN standards.
What flange materials are available?
Carbon steel flanges in SS400 and A105N, and stainless steel flanges in F304 / 304L and F316 / 316L.
Can I buy flanges in Johor Bahru?
Yes. Meta Piping is located at 23, Jalan Maju Cemerlang 2, Taman Perindustrian Maju, 81800 Johor Bahru. Contact us in advance to arrange a visit, or send your enquiry online.
Can I order flanges online?
Yes. Send your requirement through our enquiry form or to sales@meta-piping.com. We work on a quotation basis and confirm availability and pricing before the order is confirmed.
What is the difference between a slip-on flange and a blind flange?
A slip-on flange has a bore and slides over the pipe before being welded in place, connecting two sections of a line. A blind flange has no bore and is used to close off the end of a pipe, valve or vessel opening.
